BHD-130S Horizontal Shape Doypack Packing Machine | HFFS Machine

BHD-130S Horizontal Form Fill Seal Machine is specially designed for stand-up pouches with shaped cutting. This type of the doypack packing machine's filling capacity is 1-350g and packing speed from 30-60ppm. It can be used to package functional drinks, enzyme puree and other liquids products. This is a compact HFFS machine with seventeen work stations, ensuring accurate filling and packaging speed, and it is flexible. Air flushing device with air blowing function make sure the bag bottom will opening better,will

Packaging Capacity

35-45ppm

Filling Capacity

350ml

Pouch Width

60-130mm

Function

Doypack,Shape

Get a quote on WhatsApp Email inquiry

Technical Parameters

Model	Pouch Width	Pouch Length	Filling Capacity	Packaging Capacity	Function	Weight	Powder	Air Consumption	Machine Dimensionsl
BHD-130S	60-130mm	80-190mm	350ml	35-45ppm	Doypack,Shape	2150kg	6kw	300NL/min	4720mm1125mm1550mm
BHD-240DS	80-120mm	120-250mm	300ml	70-90ppm	Doypack,Shape	2300kg	11KW	400NL/min	6050mm1002mm1990mm

Engineering & Features

How To Make Sure The Bag Sealing Quality?

Air flushing device with air blowing function make sure the bag bottom will opening better,will helpful for the filling process,finally make the sealing position without product,not influenced the sealing quality.At the same time,top sealing include hot seal and cold seal,make sure the sealing more stronger.

How To Ensure Accurate Filling?

We use servo piston pump filler,this device with high filling accuracy.at the same time,according to the bag type/bag material,we can choice to produce “bag opening keeping device” to make sure when the bag move to the filling station,the bag opening 100%.

Is The Machine Easy To Operate?

1 staff enough for operate the machine.as supplier,we will provide customer the operate manuel/running video to teach customer use the machine.

Can The Machine Use For Different Design?

One of our machine can adjust bag size/filling weight/bag type.(according to the machine technical specification.
