Boevan BHD-180S Horizontal Form-Fill-Seal Machine is a standard stand-up pouch packaging machine with a packaging capacity of 1-1000ml. It is commonly used to package ketchup, sugar, biscuits,nuts, powder products, and etc., The HFFS Machine often has flexible functional applications, such as hanging holes, traction, suction nozzles and other functions. If you require packaging equipment with a larger capacity, please contact us. Heat sealing first, then cold sealing. After two sealings, the airtightness of the bag
| Model | Pouch Width | Pouch Length | Filling Capacity | Packaging Capacity | Function | Weight | Power | Air Consumption | Machine Dimensions(L*W*H) |
|---|---|---|---|---|---|---|---|---|---|
| BHD-180S | 90-180mm | 110-250mm | 1000ml | 40-60ppm | DoyPack,Shape,Hanging Hole | 2150kg | 9kw | 300NL/min | 6093*1083*1908mm |
| BHD-180SZ | 90-180mm | 110-250mm | 1000ml | 40-60ppm | DoyPack,Shape,Hanging Hole,Zipper | 2150kg | 9kw | 300NL/min | 6853*1250*1900mm |
| BHD-180SC | 90-180mm | 110-250mm | 1000ml | 40-60ppm | DoyPack,Shape,Hanging Hole,Spout | 2300kg | 9kw | 300NL/min | 6853*1250*1900mm |
Heat sealing first, then cold sealing. After two sealings, the airtightness of the bag is ensured.
Through bag opening detection and assisted air blowing, the bag opening is more complete.
Use the most suitable cutting equipment and use two cutting methods to make cutting more accurate.
By adjusting the temperature of the sealing block, the seals more smoothly.
