BHD SERIES · BHD-180S

BHD-180S Horizontal Doypack Packing Machine For Liquid Granule Powder

Boevan BHD-180S Horizontal Form-Fill-Seal Machine is a standard stand-up pouch packaging machine with a packaging capacity of 1-1000ml. It is commonly used to package ketchup, sugar, biscuits,nuts, powder products, and etc., The HFFS Machine often has flexible functional applications, such as hanging holes, traction, suction nozzles and other functions. If you require packaging equipment with a larger capacity, please contact us. Heat sealing first, then cold sealing. After two sealings, the airtightness of the bag

Packaging Capacity
40-60ppm
Filling Capacity
1000ml
Pouch Width
90-180mm
Function
DoyPack,Shape,Hanging Hole

See it run

Watch the machine run

Technical Parameters

ModelPouch WidthPouch LengthFilling CapacityPackaging CapacityFunctionWeightPowerAir ConsumptionMachine Dimensions(L*W*H)
BHD-180S90-180mm110-250mm1000ml40-60ppmDoyPack,Shape,Hanging Hole2150kg9kw300NL/min6093*1083*1908mm
BHD-180SZ90-180mm110-250mm1000ml40-60ppmDoyPack,Shape,Hanging Hole,Zipper2150kg9kw300NL/min6853*1250*1900mm
BHD-180SC90-180mm110-250mm1000ml40-60ppmDoyPack,Shape,Hanging Hole,Spout2300kg9kw300NL/min6853*1250*1900mm

Engineering & Features

How To Ensure The Bag Is Well Sealed?

Heat sealing first, then cold sealing. After two sealings, the airtightness of the bag is ensured.

How To Ensure The Integrity Of Bag Opening?

Through bag opening detection and assisted air blowing, the bag opening is more complete.

How To Ensure Accurate Cutting?

Use the most suitable cutting equipment and use two cutting methods to make cutting more accurate.

How To Improve The Aesthetics Of Bags?

By adjusting the temperature of the sealing block, the seals more smoothly.
