BHD SERIES · BHD-240SC

BHD-240SC Horizontal Doypack Packing Machine With Spout | HFFS Machine

Boevan BHD-240SC Horizontal Doypack Packing Machine is specially designed for stand-up bags with spout/cap/valve. It can make larger bag sizes and filling volumes, with a maximum filling volume of 2000ml. The suction nozzle can be designed as a straight suction nozzle or an angled suction nozzle. Often used to package large quantities of laundry detergent, milk, juice, and detergents. Servo filling nozzle can up and down according to the liquid level,to reduce the foam when filling;at the same time,the inside of th

Packaging Capacity
40-60ppm
Filling Capacity
2000ml
Pouch Width
100-240mm
Function
DoyPack,Shape,Hanging Hole

See it run

Watch the machine run

Technical Parameters

ModelPouch WidthPouch LengthFilling CapacityPackaging CapacityFunctionWeightPowerAir ConsumptionMachine Dimensions(L*W*H)
BHD-240S100-240mm120-320mm2000ml40-60ppmDoyPack,Shape,Hanging Hole2300kg11kw400NL/min7000*1243*1878mm
BHD-240SZ100-240mm120-320mm2000ml40-60ppmDoyPack,Shape,Hanging Hole,Zipper2500kg11kw400NL/min7738*1243*1878mm
BHD-240SC100-240mm120-320mm2000ml40-60ppmDoyPack,Shape,Hanging Hole,Spout2500kg11kw400NL/min8100*1243*1878mm

Engineering & Features

How To Solve The Problem Of Dripping/Foaming When Filling?

Servo filling nozzle can up and down according to the liquid level,to reduce the foam when filling;at the same time,the inside of the nozzle,will add plug for solve the dripping problem;the air blowing function also is useful for different situation.

How To Ensure The Integrity Of Bag Opening?

Through bag opening detection and assisted air blowing, the bag opening is more complete.

How To Ensure Accurate Cutting?

Use the most suitable cutting equipment and use two cutting methods to make cutting more accurate.

How To Improve The Aesthetics Of Bags?

By adjusting the temperature of the sealing block, the seals more smoothly.
