High Performance BHS-210D Duplex Horizontal Flat-Pouch Packing Machine

BHD SERIES · HIGH

High Performance BHS-210D Duplex Horizontal Flat-Pouch Packing Machine

BHS-210D is a duplex horizontal sachet packing designed for small and medium-sized flat bags, and can produce two bags at a time, doubling the production capacity. The packaging capacity is 150ml and packing speed can arrived 100ppm. Three-side sealing or four-side sealing can be selected according to customer needs, or the shape of the edge sealing. It is often used to package cosmetics. , insecticide powder, medicines, Nutritional Supplements, and etc. First,the servo pulling system made the bag moving stable,Bag

Packaging Capacity

80-100ppm

Filling Capacity

150ml

Pouch Width

60-105mm

Function

3 side seal,4 side seal

Get a quote on WhatsApp Email inquiry

See it run

Technical Parameters

Model	Pouch Width	Pouch Length	Filling Capacity	Packaging Capacity	Function	Weight	Power	Air Consumption	Machine Dimensions(LWH)
BHS-210D	60-105mm	90-225mm	150ml	80-100ppm	3 side seal,4 side seal	1250kg	4.5kw	200NL/min	43009701500mm
BHS-240D	70-120mm	100-225mm	180ml	80-100ppm	3 side seal,4 side seal,Twin Bag	1250kg	4.5kw	200NL/min	45009701500mm

Engineering & Features

How To Confirm The Bag Sealing Stronger？

First,the servo pulling system made the bag moving stable,Bag positioning precision, bag sealing without deviation.then we have two sets of top sealing device make sure the sealing good.

How To Improve The Success Rate Of Bag Opening?

First,we opening the machine by Vacuum generator or vacuum pump,according to customer real needs;then for some special film material,we can add the “bag opening keeping function”.

How To Ensure The High Filling Accuracy?

First,use high quality filling device for make sure the filling accuracy is good;second,for different character product,we will add different function for help the filling.
