BVS SERIES · BVS6-680
BVS6-680 Multi-Lane Stick Bag Packing Machine | Vertical Form-Fill-Seal with CSA
The BVS6-480/680 multi-lane stick bag packing machine is highly popular within the pharmaceutical, nutraceutical, and food and beverage industries—specifically for products such as protein powder, probiotic powder, mixed powder blends, milk powder, instant coffee, liquid coffee and more. This 6-lane packaging system boasts a maximum output capacity of up to 300 bags per minute. Should you have any specific requirements, please feel free to leave a message to receive a personalized solution design from one of our en
Packaging Capacity
160
Pouch Width
17-50mm
Weight
1800
See it run
Technical Parameters
| Model | Pouch Length | Pouch Width | Packaging Capacity | Film width | Lanes No | Weight | Machine Dimensions(L*W*H) |
|---|---|---|---|---|---|---|---|
| BVS4-480 | 50-180mm | 17-50mm | 160 | 480mm | 4 | 1800 | 1530*1880*2700mm |
| BVS6-480 | 50-180mm | 17-30mm | 240 | 480mm | 6 | 1900 | 1530*1880*2700mm |
| BVS6-680 | 50-180mm | 17-45mm | 240 | 680mm | 6 | 2000 | 1730*1880*2700mm |
| BVS8-680 | 50-180mm | 17-30mm | 320 | 680mm | 8 | 2100 | 1730*1880*2700mm |
Engineering & Features
How To Ensure The Bag Is Well Sealed?
Heat sealing first, then cold sealing. After two sealings, the airtightness of the bag is ensured.
How To Ensure Accurate Cutting?
Use the most suitable cutting equipment and use two cutting methods to make cutting more accurate.
How To Improve The Aesthetics Of Bags?
By adjusting the temperature of the sealing block, the seals more smoothly.
