BRS SERIES · BRS-4S
BRS-4S/6S Rotary Bag Feeder | Spout Pouch Filling and Capping Machine
BRS-4S/6S Rotary Premade Pouch Packing Machine designed for spout-pouch with multi-heads filling nozzle. The speed can reach 60 bags per minute This is a automatic spout pouch filling and capping machine capable of handling large volumes exceeding 3 liters. Usually used for package jelly, laundry detergent, juice, tomato suace, oil, and other liquid products, also contain chicken essence and other powders and granules.
See It Run
Real footage from our Shanghai factory — filmed running production.
Rotary Premade Pouch — Milk PowderBRS rotary filling milk powder into premade stand-up pouches
Spout Pouch Filling & CappingBRS rotary line filling and capping spouted pouches
See it run
Technical Parameters
| Model | BRS-4S | BRS-6S |
|---|---|---|
| Head number | 4 | 6 |
| Max bag height | 250mm | 250mm |
| Nozzle diameter | 8.5-20mm | 8.5-20mm |
| Maximum loading | 2000ml | 2000ml |
| Packaging speed | 100ml/5200-5500ppph | 100ml/7800-8200pph |
| 300ml/4600-4800pph | 300ml/6900-7200pph | |
| 500ml/3800-4000pph | 500ml/5700-6000pph | |
| Met ering accura cy | <±1.0% | <±1.0% |
| Powder consumption | 4.5KW | 4.5KW |
| Gas consumption | 400NL/min | 500nl/min |
| Machine Dimensions(L*W*H) | 1550*2200*2400mm | 2100*2600*2800mm |
Engineering & Features
How To Ensure The Bag Is Well Sealed?
Heat sealing first, then cold sealing. After two sealings, the airtightness of the bag is ensured.
How To Ensure The Integrity Of Bag Opening?
Through bag opening detection and assisted air blowing, the bag opening is more complete.
How To Improve The Aesthetics Of Bags?
By adjusting the temperature of the sealing block, the seals more smoothly.
